Lens Edger Profesional untuk Presisi Maksimal
Tingkatkan efisiensi dan akurasi pemotongan lensa di optik Anda dengan mesin Lens Edger berkualitas
3D Intelligent Edger – PLE6800
Super – large and super – clear touch screen,super cost performance. Split module design, convenient and simple after – sales maintenance to save time and cost ultra – high speed and grinding efficiency with motor w/o belt, axis displacement is almost perfect.
Edger Technical Index
- Max. number of the stored images : 1000 PCs
- Max. cutting diameter : 80mm
- Mini. beveling size : 26mm
- Mini flat edging size : 25mm
- Max. frame center distance : 100mm
- Diameter of diamond wheels group : 100mm x 3
- Display : 10.4″ TFT LCD Touch Screen
- Input voltage : AC 220V 50Hz, AC 110V 60 Hz
- Output voltage : DC 5V 4.6A, DC 24V 4.6A
- Power consumption : 1 Kw
- Beveiling postion : Stepless adjustment (20%-80%)
- Gross Weight : 70 Kg
- Nett Weight : 51 Kg
- Dimensions : 700 mm x 580 mm x 750 mm
3D Intelligent Edger – PL6800
Super – large and super – clear touch screen,super cost performance. Split module design, convenient and simple after – sales maintenance to save time and cost ultra – high speed and grinding efficiency with motor w/o belt, axis displacement is almost perfect.
Edger Technical Index
- Max. number of the stored images : 1000 PCs
- Max. cutting diameter : 80mm
- Mini. beveling size : 26mm
- Mini flat edging size : 25mm
- Max. frame center distance : 100mm
- Diameter of diamond wheels group : 100mm x 3
- Display : 10.4″ TFT LCD Touch Screen
- Input voltage : AC 220V 50Hz, AC 110V 60 Hz
- Output voltage : DC 5V 4.6A, DC 24V 4.6A
- Power consumption : 1 Kw
- Beveiling postion : Stepless adjustment (20%-80%)
- Gross Weight : 70 Kg
- Nett Weight : 51 Kg
- Dimensions : 700 mm x 580 mm x 750 mm
Tracer – PLE780
Features :
- Low failure, simple and easy operation
- Precise tracing, accurate grinding, effective tool for lens processing.
- Demo Lens tracing ( rimless, half rimless )
- Frame tracing ( full frame )
Tracer technical data :
- Tracing type : Frame Tracing (Full frame), Demo Lens Tracing (rimless, half rimless)
- Tracing Time : Less than 20s
- Tracing Acuracy : 0.1 mm
- Power source : AC 100 – 240 V 50-60Hz
- G.weight : 7 Kg
- N.weight : 5 Kg
- Dimesion : 300 x 280 x 340mm
Demo lens tracing
Frame Tracing
External interface
External interface
Tracer – PLE780
Features :
- Low failure, simple and easy operation
- Precise tracing, accurate grinding, effective tool for lens processing.
- Demo Lens tracing ( rimless, half rimless )
- Frame tracing ( full frame )
Tracer technical data :
- Tracing type : Frame Tracing (Full frame), Demo Lens Tracing (rimless, half rimless)
- Tracing Time : Less than 20s
- Tracing Acuracy : 0.1 mm
- Power source : AC 100 – 240 V 50-60Hz
- G.weight : 7 Kg
- N.weight : 5 Kg
- Dimesion : 300 x 280 x 340mm
Demo lens tracing
Frame Tracing
External interface
External interface
Power swtich & external interface
Manual/ motorized dual-use rocker arm
Scanner with central positioning – PLE 680
Exclusive patented optical system design Excellent graphics effects processing capability Manual/motorized integrated center positioning, fast working and smooth pressure
Specifications:
- Adopting a dual telecentric optical imaging system
- Manual/ motorized integrated central positioning structure
- Display screen : 8-inch color TFT LCD touch Screen
- Scanning time : < 3s
- Scanning Precission : 0.1mm
- Power Source : AC100-240V 50/60 Hz
- Gross Weight : 12 Kg
- Nett Weight : 11 Kg
- Dimension : 430mm x 340mm x 590mm
- Electric Motor : DC12V
Central Positioning
Scanner with central positioning
PLE 680
Power swtich & external interface
Manual/ motorized dual-use rocker arm
Exclusive patented optical system design Excellent graphics effects processing capability Manual/motorized integrated center positioning, fast working and smooth pressure
Specifications:
- Adopting a dual telecentric optical imaging system
- Manual/ motorized integrated central positioning structure
- Display screen : 8-inch color TFT LCD touch Screen
- Scanning time : < 3s
- Scanning Precission : 0.1mm
- Power Source : AC100-240V 50/60 Hz
- Gross Weight : 12 Kg
- Nett Weight : 11 Kg
- Dimension : 430mm x 340mm x 590mm
- Electric Motor : DC12V
Central Positioning
